Do you face difficulties in opening or closing the shutters every day? Do you find yourself having to lean dangerously out of the window or give up natural light because it is too uncomfortable? USHADE KSW900-1-SH-C-LU is the perfect solution to make your life easier.
Resolved issues:
Shutters in awkward positions (behind washing machines, above kitchen countertops, etc.).
Difficulty in opening and closing shutters due to height or architectural barriers.
Avoid the ingress of cold in winter and hot in summer when adjusting the shutters.
Exclusive benefits of USHADE:
Simple and Non-invasive Installation: already assembled, wired and tested. No masonry work necessary.
Weatherproof: Solid aluminum box for long life.
Universal Compatibility: Fits most shutters due to its compact design.
Advanced Safety: double mechanical and electronic clutch for total protection.
Smart control: manage your shutters from your smartphone wherever you are, with full compatibility with Google Home and Alexa.
Ready to Use: installation in a few minutes.
Package Contents:
Motorized crosshead complete with motor and control unit
The movement lever(s) with mechanical clutch
Wi-Fi receiver for connection with Google Home or Alexa apps or management systems
Free cut-to-size on request to be included in the comments to the order
Motorized crosshead electrical characteristics:
Feeding | 230 V / 50-60 Hz |
Absorption | 0.3 A |
Gear motor pair | 23 Nm |
Maximum Capacity | 30 Kg + 30 Kg (2 doors) |
Opening time | 12 s / 180° |
Class of Service | 2 = LIGHTWEIGHT |
Intermittence | S2 = 7 min, S3 = 15% |
Operating Temperature | -20 °C / +55 °C |
Degree of protection | IP44 (with cover) |
Motor power supply | 12 V / 1.4 A |
The motorized crossbar is a product YAW conceived, designed and manufactured entirely in Italy.
- Command
- Radio
Wi-Fi - Max shutter width
- 800 mm
- Shutter width min.
- 300 mm
- Electric motor
- 230V
- N. ante
- Double
- Leaf weight
- 30 Kg + 30 Kg
- Type of dark
- A book
Swing
