Kit gearmotor 24V overhead doors counterweights 7 sqm DITEC ENTREMATIC DOITBXL

DITEC ENTREMATIC DOITBXL NADOITBXL

Kit including built-in control panel and 433MHz radio

Automations with mounting on canvas for overhead doors with counterweights up to 7 square meters

24V motor kit for overhead doors with counterweights up to 7 m2

built-in control panel with 433 MHz radio

optional slave actuator code BOX3H

Kit composition :

1 gearmotor BOX3EH

1 fixing base

1 key unlock

1 E1HBOX control panel incorporated in the motor

1 opening limit switch already mounted

1 x 433MHz ZEN4 rolling code remote control (4 channels)

Description Box 3EH

Electromechanical actuator for tilting counterweights

Encoder stroke management + rotary limit switch

Maximum capacity 7 sqm (1 engine) 12 sqm (2 motors in parallel)

Class of service 3 - frequent

Intermittency S2 = 30 min S3 = 50%

Power supply 24 Vdc

Absorption 8 A Torque 300 Nm

Opening time 15÷30 s

Release for manual lever / key opening

Operating temperature -20°C / +55°C

Protection degree IP 40 Product dimensions (mm) 660x100x120

Control panel E1HBOX (built-in)

It is contained in an ABS casing and is equipped with a courtesy light,

which turns on automatically upon receipt of the opening command.

Warranty 24 Months
