Pair of photocells photocell Slim outdoor wall NICE EPSB BUS Original

NICE EPSB Era Photocell S

Synchronized Slim photocells, fixed, also with BlueBUS NICE technology
Safe: type D device according to EN12453 that allows to detect obstacles present on the optical axis between transmitter (TX) and receiver (RX).
Using the phototest function it is possible to achieve category 2 fault safety according to EN 954-1.
Anti-glare circuit that eliminates possible interference from sunlight.
Practical: reception angle 8.
Resistant, also in anti-burglary version: ABS shell resistant to atmospheric agents, also available in anti-burglary version with metal body.
BlueBUS NICE technology: available with BlueBUS NICE system, which allows easy connection to the control panel of all devices with only two wires, simply by connecting them in parallel and selecting the addressing jumpers according to the required function.
The system automatically acquires devices connected to the BlueBUS network.
Automatic synchronization between multiple pairs of photocells to avoid other interference between devices.
IB interface: allows you to connect presence detectors with NICE BlueBUS technology to control panels equipped with inputs for traditional contacts.

SPECIFICATIONS:
Rated flow rate (m): up to 15 for TX-RX offset maximum 5 (the device can signal an obstacle even in adverse weather conditions)
Output power: the device can only be connected to BlueBUS networks from which it draws the power supply and sends the output signals
Degree of protection (IP): 44
Operating Temp (C min/Max): -20 +50
Dimensions (mm): 30x27x106 h
Weight (g) : 120

Warranty 24 Months
