The ZENXR2 DITEC universal receiver is the ideal solution for those who want a compact, reliable and versatile device for controlling gates, garage doors and industrial automation. Thanks to its two independent channels, it allows you to manage different functions or two separate automations with a single receiver.

It operates at the standard frequency of 433.92 MHz and is powered by 12-24 V AC/DC, with low power consumption and great reliability. The two relay outputs provide a normally open dry contact, capable of handling safe and precise commands.

At the heart of the system is the removable BIXMR2 memory module, which allows up to 200 transmitters to be stored. This allows for quick and easy management of remote controls: simply replace the module to clone settings or make a full backup.

The ZENXR2 receiver supports multiple transmission protocols, including fixed code, rolling code, AES-128, and Protected mode, providing a high level of security against unauthorized duplication of signals. It is also fully compatible with ZEN' DITEC range of transmitters and radio keypads, making it extremely flexible even in existing installations.

The built-in rigid antenna ensures stable reception, but an external antenna can also be connected to further increase the range in difficult conditions. The compact and robust housing allows for quick and easy installation, both on the wall and inside electrical cabinets.

Key benefits:

• Two independent channels to control multiple functions or automations.

• Management of up to 200 remote controls with removable memory.

• Maximum security thanks to rolling code and AES-128 protocols.

• Universal compatibility with DITEC ZEN transmitters and other devices.

• Quick installation thanks to pre-wiring and the possibility of an external antenna.

The ZENXR2 DITEC is therefore an original spare part designed to offer reliability, safety and ease of use, perfect both for new installations and for replacing older receivers.
