Gear Motor Single Actuator Motor with 24v central NICE HO7124 Original

NICE HO7124 Hopp
For swing gates with leaves up to 2.4 m, even in the presence of large columns and light structures
Ideal for intensive use.
Irreversible electromechanical gearmotor 24 Vdc, articulated arm and external mounting.
Two irreversible 24 Vdc versions with mechanical stops with millimeter adjustment in opening and closing: with integrated control unit (HO7124) and without control unit (HO7224).
Powerful thanks to the torque of 250 Nm.
Durable and compact: 180 mm wide, ideal for any column. Shockproof body of reduced dimensions with aluminum base.
Sturdy aluminum anti-shearing arm. Easy to install: thanks to the new fixing bracket with quick coupling for the motor. No welding.
Sophisticated electronics with integrated control panel, only 3 buttons to manage programming operations:
obstacle detection and possibility of connection to the sensitive edge 8.2 KOhm, phototest;
automatic diagnosis of anomalies;
self-learning of limit switches in opening and closing;
possibility to configure the stop input in self-learning, Na, Nc and resistive sensitive edges of the latest generation 8.2 KOhm;
slowdown in opening and closing;
easy possibility to connect pairs of additional photocells;
pause time scheduling;
opens pedestrian and partially opens;
Clutch with anti-crushing safety.
Energy saving and no blackout: 3 standby modes to reduce consumption from the mains, or from the battery if connected to the Solemyo kit. Operation even in power failure thanks to optional batteries (PS124).
Everything under control: thanks to the provision for the Opera BUS T4 system, it is possible to use the O-View unit to expand the possibilities of programming, control and diagnostics of automation on site and remotely.

SPECIFICATIONS:
Power supply (Vac 50/60 Hz): 230
Power supply (Vdc): -
Absorption (A): 1,3
Power (W): 280
Speed (rpm): 1,68
Torque (Nm): 250
Duty cycle (cycles/hour): 35
Degree of protection (IP): 54
Operating Temp (C Min/Max): -20 +50
Dimensions (mm): 252x180x290 h
Weight (kg): 9

Warranty 24 Months
