FAAC 785104 – Pair of 20W adjustable 24V wired or wireless photocells with IP54 battery
Pair of FAAC XP 20W photocells (EAN 8055195012392) with battery-powered or wired wireless transmitter and traditional 4-wire receiver.
Automatic alignment, horizontal orientation angle -90° / +90° and range up to 20 meters.
Ideal for installations where it is not possible to pass cables or do masonry work.
IP54 degree of protection – 12/24V AC/DC power supply – CR2 battery (3V) not included.
Lowest price within 30 days before promotion. €67.00
Fast delivery
Available material shipped within 2-3 days
Secure payment
Verified payment systems
Collection points
+30,000 collection points in Italy
Product guarantee
Direct guarantee from our store
Return guaranteed
14 days for returns
Related articles
-
Is UGATE SHOP a reliable seller? What are customers' opinions?
In this post we report on the opinions of some of our customers who have been super satisfied with our service and...Read more -
Single photocell that replaces all traditional photocells and reflexes
Thanks to ToF laser technology, OPTIGATE can replace any pair of photocells and reflex photocells, operating...Read more
-
Summer Break ugateshop.it: what to know about shipping, support, and discounts
We’re also taking a short break in August, but our shop remains online at all times. In this article, you’ll find all...Read more
The FAAC XP 20W photocells represent the most versatile and modern solution in the FAAC range, thanks to the possibility of powering the transmitter (TX) both in wired mode and via a 3V CR2 battery.
This feature allows the photocell to be installed even at a great distance from the control unit, eliminating the need for masonry work or conduits for the passage of cables.
The receiver (RX) works with 4 wires, like traditional photocells, ensuring maximum compatibility with FAAC control panels and other manufacturers.
The system is equipped with optical self-alignment and adjustable mechanical orientation from -90° to +90°, for precise positioning even on surfaces that are not perfectly aligned.
The XP 20W are perfect for residential and condominium systems, ensuring a range of up to 20 meters, high reliability over time and stable operation even in difficult environmental conditions (from -20°C to +55°C).
The IP54 degree of protection makes them suitable for outdoor use, while the FAAC technology ensures build quality, precision and durability.
Specifications
• Model: XP 20W
• Product code: 785104
• EAN: 8055195012392
• Brand: FAAC
• Device type: Pair of adjustable photocells for outdoor use
• Maximum range: 20 m
• Alignment: Automatic
• Landscape orientation: -90° / +90°
• RX power supply: 12 ÷ 24V AC/DC
• TX power supply: 12 ÷ 24V AC/DC or CR2 3V battery (not included)
• Power consumption: RX 30 mA – TX 40 mA (battery) / 5 mA (at 24V)
• Degree of protection: IP54
• Operating temperature: -20°C ÷ +55°C
• Installation: Wall mounted
• Dimensions (L × D × H): 41.5 × 42.5 × 130 mm
Strengths
• Wireless transmitter: cable-free installation
• Optical self-alignment for easy mounting
• Adjustable to 180° overall (-90°/+90°)
• Range up to 20 meters
• Compatible with all FAAC control panels and other brands
• Ideal for installation on finished walls or columns
• Reliable operation in all weather conditions
Recommended Applications
FAAC or compatible automations for sliding gates, swing gates, up-and-over doors, barriers and residential or condominium accesses where installation flexibility is required.
