HOPP Automation Kit for articulated swing gates NICE HOPPBDKCE 24v

NICE HOPPBDKCE Hoppkit BD

EAN 8032595795162

For swing gates with leaves up to 2.4 m, even in the presence of large columns and light structures
Ideal for intensive use.
Irreversible electromechanical gearmotor 24 Vdc, articulated arm and external mounting.
Two irreversible 24 Vdc versions with mechanical stops with millimeter adjustment in opening and closing: with integrated control unit (HO7124) and without control unit (HO7224).
Powerful thanks to the torque of 250 Nm.
Durable and compact: 180 mm wide, ideal for any column. Shockproof body of reduced dimensions with aluminum base.
Sturdy aluminum anti-shearing arm. Easy to install: thanks to the new fixing bracket with quick coupling for the motor. No welding.
Sophisticated electronics with integrated control panel, only 3 buttons to manage programming operations:
obstacle detection and possibility of connection to the sensitive edge 8.2 KOhm, phototest;
automatic diagnosis of anomalies;
self-learning of limit switches in opening and closing;
possibility to configure the stop input in self-learning, Na, Nc and resistive sensitive edges of the latest generation 8.2 KOhm;
slowdown in opening and closing;
easy possibility to connect pairs of additional photocells;
pause time scheduling;
opens pedestrian and partially opens;
Clutch with anti-crushing safety.
Energy saving and no black out: 3 standby modes to reduce mains consumption, or battery consumption if connected to the Solemyo kit. Operation even in power failure thanks to optional batteries (PS124).
Everything under control: thanks to the provision for the Opera BUS T4 system, it is possible to use the O-View unit to expand the possibilities of programming, control and diagnostics of automation on site and remotely.

THE KIT CONTAINS:

2x HO7124 + HO7224 Electromechanical gearmotor with external mounting, with integrated control unit and OXI plug-in receiver.

2x ON3EBD 3-channel 433.92MHz transmitters, bidirectional

(ATTENTION, due to production delays, NICE can insert the ON2E version in the kit, without notice)

1x EPMB Pair of outdoor photocells prepared for connection via NICE BlueBUS.

1x ELDC Flashing light with built-in antenna

1 TS Signage table

The manuals will no longer be provided in paper format, but only via QR Code.

Warranty 24 Months
