Single actuator gear motor without central NICE HK7224 Original

NICE HK7224 Hyke
For swing gates with leaves up to 3.5 m, even in the presence of large columns
Ideal for intensive use.
Irreversible electromechanical gearmotor with articulated arm, external mounting, 24 Vdc, with magnetic encoder.
Reliability and durability: thanks to the aluminum body with polyester paint, resistant to atmospheric agents.
Safe: obstacle detection and monitoring of engine absorption along the stroke, self-diagnosis through the flashing light and LED courtesy light.
Prepared for the connection of optical and resistive 8.2 KOhm sensitive edges of the latest generation.
Two irreversible versions 24 Vdc with limit switch in opening and closing: with integrated control panel
(HK7024) and without control panel (HK7224).
Practical and fast installation: the articulated arm adjustable in length for maximum flexibility.
Simple and precise adjustment of limit switches: mechanical stops and micrometric adjustment screws.
Easy to operate lever release: with metal lock and custom key NICE.
Prepared for rope control.
Saving, respect for the environment, autonomy: connected to the backup battery or to the Solemyo kit the standby consumption of only 0.1 W.
No blackout: operation in the absence of power with optional batteries (PS124) housed inside the motor.
Integrated control unit (HK7024):
simple programming, with a single button;
self-learning of limit switches in opening and closing;
self-diagnosis of anomalies;
pause time scheduling;
pedestrian door;
slowdown in opening and closing;
dual-tech obstacle detection;
Prepared for the connection of the latest generation of sensitive edges.

SPECIFICATIONS:
Power supply (Vac 50/60 Hz): -
Power supply (Vdc): 24
Absorption (A): 6
Power (W): 140
Speed (rpm): 1,5
Torque (Nm): 500
Duty cycle (cycles/hour): 40
Degree of protection (IP): 54
Operating Temp (C Min/Max): -20 +50
Dimensions (mm): 290x210x320 h
Weight (kg): 9.5

Warranty 24 Months
