IRONLATCH220-N – 230V safety electric post

If you are looking for an electric lock that can offer maximum security and reliability over time, IRONLATCH220-N is the ideal professional solution.

This new version completely replaces the previous IRONLATCH220 model, maintaining all its functional characteristics and further improving the structure. The aesthetics have been slightly revised making the body more compact, while the watertightness has been optimized, making the product even more suitable for outdoor installation.

The electric post is made entirely of high-strength metal and is designed to withstand high mechanical stress. The 19 mm diameter steel pin, with a 20 mm stroke, guarantees a deep and safe engagement, effectively counteracting burglary attempts.

With a power of 75 W and a power consumption of 1.2 A, IRONLATCH220-N ensures a firm and constant locking, ideal for swing gates, sliding gates or special solutions where an additional high-security locking point is required.

Technical features

Power supply: 230 V

Power consumption: 1.2 A

Power: 75 W

Length: 95 mm

Width: 105 mm

Height: 73 mm

Axle travel: 20 mm

Pin diameter: 19 mm

Structure: all-metal

Upgraded version: more compact and better watertight

Important note

IRONLATCH220-N completely replaces the previous IRONLATCH220 model.

The product code has been updated from YAW-008000009 to YAW-001000213.

Technical recommendation for condominium use

In the case of installation of IRONLATCH220-N (MPN: YAW-001000213) on condominium entrances or on gates with prolonged manoeuvring times, the use of a dedicated timer card is strongly recommended.

The timer card allows you to limit the time the lock is powered, preventing the electrobollard from being attracted for the entire duration of the opening and closing of the gate.

This technical trick is essential to:

reduce thermal and electrical stresses on the coil,

prevent overheating in the event of long or frequent manoeuvres,

increase the reliability and durability of the lock,

make the system more suitable for intensive use contexts such as condominiums and shared accesses.

The use of timing is therefore a good installation practice, especially in the professional field.
